Air-Hydraulic Brake System for Deuce and a Half (Conversion from Air-Pack, Air-Over-Hydraulic)

Air-Hydraulic Brake System for Deuce and a Half (Conversion from Air-Pack, Air-Over-Hydraulic)
Item# AHM35A2
$1,500.00
Master Cylinder:  Air Valve Mounting:  Air Gauge:  Brake Light Switch (Your Vehicle Likely Already Has One If You Are Converting):  Low Air Indicator and Warning Buzzer:  Safety Valve:  Air Hose:  Pump and Air Tank:  Plus Shipping for Pump and Air Tank:  Shipping:

Product Description

Replacement parts for the original Air-Pack system are getting harder to find, and what is available is generally of low quality. This converts it, with all brand new parts, to reliable and much more supportable air brake parts. Converting to air-hydraulic makes everything the same as full air-brakes, except that you don't have to change your hydraulic brake axles to do it.

Our Air-Hydraulic brake system uses an air-valve/pedal assembly to apply a remotely mounted air brake booster. It uses air pressure from a belt driven or 12 volt onboard air system to control the air-hydraulic booster, just like the brake system on super sized big rigs and buses, but it pushes a master cylinder rather than the roller cam that mechanically spreads the brake shoes apart on full air brake systems, so it will operate your existing hydraulic brake calipers or drums. It is great for vehicles with a lot of horsepower, a lot of weight, limited firewall clearance, that don't have power steering pressure or enough vacuum to run other brake systems, and/or already have air tanks onboard for operating air-ride suspension or air powered tools.

Most of the system is mounted remotely, usually on the frame or in the trunk. The only thing attached to your brake pedal is the air valve that is about the size of your fist, and you can even remove the stock pedal altogether and go with a pedal that we supply that mounts on the floorboard and puts the valve on the other side of the floorboard. You will have air pressure come in from the tank to the valve, and another air hose that goes from the valve to the booster/master that is on the frame. The booster has two chambers, one does the normal brake application, and the other is the emergency/parking brake. You will have another valve that you can mount on the dash, or hide under the seat or dash, which you can push and pull to manually apply a hydraulic parking brake that locks all four wheels. The hydraulic parking brake feature is much more powerful than the standard cable parking brake, can serve as an anti-theft device if the valve is hidden, and is there to also apply the brakes if you lose air. The system can be built with just the service chamber and no parking brake chamber if it is unneeded or unwanted in your application. If a set of glad hands is also installed, this system will allow your vehicle with hydraulic calipers or drums to pull a trailer that is equipped with air-brakes, or a trailer with hydraulic wheel cylinders that also has one of these Air-Hydraulic systems installed.

It operates off of 120-150 pounds of air pressure, which is much higher than the 15-20 pounds of vacuum that vacuum brake setups use (if the engine is producing enough or any vacuum), and is more serviceable than Hydro-Vac systems that are no longer generally used. The Hydro-Max has a backup motor that assists in stopping if your engine dies, which is a great feature, the Air-Hydraulic will have 10-20 or more stops in reserve in the air tank and the air compressor will continue to produce more if the battery still provides electricity.

Systems can be setup with or without an air compressor and tank, and can easily be designed to replace obsolete systems with just a few measurements - like the master cylinder bore diameter of your current setup. Dual/split systems with multiple boosters and master cylinders that are isolated front and rear are also available and would be used for redundancy/safety or for a "limp home" mode so that one half of the brake system will work if the other fails.

Accessories

1-3/4 Inch Master Cylinder for Hydro-Max Brake System, Tall Reservoir, Deep Hole Piston (1.75 inch, 44.45 mm)
1-3/4 Inch Master Cylinder for Hydro-Max Brake System, Tall Reservoir, Deep Hole Piston (1.75 inch, 44.45 mm)

(Reservoir may appear different than pictured)

Master Cylinder Bore Diameter: 1-3/4 in

Master Cylinder Material: Cast Iron

Mounting Hole Quantity: 4

Number of Outlets: 2

Rearward Outlet Size: 9/16-18

Reservoir Included: Yes

Secondary Outlet Thread Diameter: 1/2-20

Sensor Included: No

1991-2002 Chevy GMC Medium/Heavy Truck

B7

C50

C5000

C5500 Kodiak

C6000

C6000 TOPKICK

C70

C70 Kodiak

C7000

C7000 TOPKICK

P6000

P6500
$400.00
HMMC134TDH
Shipping:
Medium Duty Air Compressor and Tank for Air-Hydraulic Brake System
Good for Air/Hydraulic Brake System, Air-Ride, and as an Off-Road on-board air system for tire refill.

MOTOR -12-Volt

- Permanent Magnetic Motor

- Duty Cycle: 33% @ 100 PSI

- Max. Working Pressure: 150 PSI

- Max. Amp Draw: 23 Amps

KIT - 2.5 Gallon Air Tank

- Compressor

- Dash Panel Gauge with ON/OFF Switch

- Pressure Switch with Relay (110 PSI on, 145 PSI off)

- Reducer: 1/8” (F) to 1/4” (M)

- 1/4” Quick Connect Coupler (M)

- 1/4” 175 PSI Safety Valve

- 1/4” Drain Cock

- 20ft. 12-Gauge Wire with Inline Fuse Holder

- 4” Strip of Continuous Grommet Material

- Accessory Airline

- Electrical Connections
$350.00
ABAKMD
Heavy Duty Air Tank and Compressor Kit for Air-Hydraulic Brake System
Good for Air/Hydraulic Brake System, Air-Ride, and as an Off-Road on-board air system for tire refill.

COMPRESSOR

- 12-Volt

- Permanent Magnetic Motor

- Duty Cycle: 33% @ 100 PSI

- Max. Working Pressure: 150 PSI

- Max. Amp Draw: 32 Amps

KIT

- 2.5 Gallon Air Tank

- Compressor

- 35ft. Coil Hose with Tire Chuck

- 1/4” Quick Connect Stud (F)

- 1/4” Quick Connect Coupler (F)

- Dash Panel Gauge with ON/OFF Switch

- Pressure Switch with Relay (110 PSI on, 145 PSI off)

- Reducer: 1/8” (F) to 1/4” (M)

- 1/4” 175 PSI Safety Valve

- 1/4” Drain Cock

- (3) 1/4” Compression Fittings

- 20ft. 12-Gauge Wire with Inline Fuse Holder

- 4” Strip of Continuous Grommet Material

- Accessory Airline

- Electrical Connections
$450.00
ABAKHD
